HORIZONTAL "EAGLE E1" 300-500 W WINDLASSES

  • windlass
036300 dis_tec_036300

Horizontal windlasses with anodized aluminium hard oxide base.

Features:
Manual chain free-fall system
• Integrated magnete and sensor for chain counter
• Watertight IP66
Thanks to the vertical motor it allows a quick and easy installation on deck.

Complete with: reverse contractor unit and nylon handle, excluding control board (optional item 036609 - 036611).

Model

without

drum

Model

with

drum

Watt

Volts

Consumption

Amp

Ø

chain

mm

Working load

Kg

Working load

Max Kg

Deck thickness

mm

Weight

Kg

Boat

m

Case

contactor/reversing contactor

Switch

hydraulic magnetic circuit breaker

036300

-

300

12

60

6

30

100

20÷40

8

5>7

036600

036625

036320

036330

500

12

90

6

80

250

20÷40

9,3

6>9

036600

036626

Availability:
  • Available
  • Not available
  • Stock not managed
